Penetrating Bitumen

Bitumen Penetration 85/100

Bitumen Penetration 60/70

Bitumen Penetration 40/50

About Our Products

Penetration or blown bitumens are produced through a process involving the reaction of vacuum bottom and air in bitumen production unit reactors. Depending on the control of process conditions, they are manufactured in various grades. Specification Table of Penetration (Blown) Bitumen

Penetration Grade-ASTM/AASHTO
Test Method	200-300	150-200	120-150	85-100	60-70	40-50	Unit	Analysis
				Limit
ASTM D70 or D3289	990-1040	1000-1050	1000-1050	1000-1050	1010-1060	1010-1060	kg/m³	Density @ 25°C
ASTM D5	200-300	150-200	120-150	85-100	60-70	40-50	mm/10	Penetration @ 25°C
ASTM D36	32 min	36 min	38min	42 min	46 min	49 min	°C	Softening Point
ASTM D113	100min	100min	100min	100min	100 min	100 min	cm	Ductility @ 25°C
ASTM D6	1max	0.5 max	0.5 max	0.5 max	0.2 max	0.2 max	%	Loss on heating
ASTM D5	20max	20max	20max	20max	20 max	20 max	°C	Drop in penetration after heating
ASTM D92	177 min	218 min	218 min	232 min	323 max	232 max	wt%	Flash point
ASTM D2042	99.09 min	99.09 min	99.09 min	99.09 min	99.09 min	99.0 min	—	Solubility in Trichloroethylene
AASHTO 102	Negative	Negative	Negative	Negative	Negative	Negative	P	Spot test
ASTM D 2171	200±50	250±50	450±90	1000±200	2000±400	4000±800	cSt	Viscosity @ 60°C
ASTM D 2170	80 min	150 min	170 min	250 min	300 min	400 min		Viscosity @ 135°C
Test on Residue From Thin Film Oven Test(ASTM D1754)
ASTM D5	40 min	46 min	46 min	50 min	54 min	58 min	%	Retained penetration after(T.F.O.T)
ASTM D113	100	100	100	75	50	50	cm	Ductility (25°C),5cm/min, cm after TFOT
ASTM D 2171	1250max		2250 max	5000 max	1000 max	2000 max	P	Viscosity @ 60°C
